Customizable ATEX Certificate Gas Injecting System for Fast and Accurate Refrigerant Charging at Production Line
-
ハイライト
ATEX Certificate Gas Injecting System
,Customizable Gas Injecting System
-
状態新品
-
適用される産業製造工場
-
体重 (kg)300
-
ショールームの場所なし
-
動画の出荷検査提供
-
機械の試験報告利用不可
-
基本部品の保証1年
-
コアコンポーネントモーター、ポンプ
-
種類コンプレッサー
-
保証1 年
-
アフターサービス提供海外で機械の修理ができる技術者
-
解像度0.1g
-
電圧380V/50Hz
-
冷媒R22/R410A/R407C/R134A
-
モデル番号CM8600 R32 冷却剤充電システム
-
精度±0.5%
-
真空度5Pa~10Pa
-
充電速度60~260g/s
-
適用するエアコン,水分器,冷蔵庫,冷蔵庫
-
港上海 寧波 天津 青島
-
起源の場所江苏,中国
-
ブランド名CM
-
証明CE, ATEX
-
モデル番号CM8600
-
最小注文数量1個
-
価格$20,400.00/units 1-2 units
-
パッケージの詳細CM8600 冷却剤充填機のための木製ケース,パレット
-
供給の能力月あたり50ユニット
Customizable ATEX Certificate Gas Injecting System for Fast and Accurate Refrigerant Charging at Production Line
Customizable ATEX Certificate Gas Injecting System for Fast and Accurate Refrigerant Charging at Production Line
| Attribute | Value |
|---|---|
| Condition | New |
| Applicable Industries | Manufacturing Plant |
| Weight (KG) | 300 |
| Showroom Location | None |
| Video outgoing-inspection | Provided |
| Machinery Test Report | Not Available |
| Warranty of core components | 1 Year |
| Core Components | Motor, Pump |
| Type | COMPRESSOR |
| Warranty | 1 Year |
| After-sales Service Provided | Engineers available to service machinery overseas |
| Resolution | 0.1g |
| Voltage | 380V/50HZ |
| Refrigerant | R22/R410A/R407C/R134A |
| Model No | CM8600 R32 refrigerant charging system |
| Precision | ±0.5% |
| Vacuum degree | 5Pa~10Pa |
| Charging speed | 60~260g/s |
| Application | Air conditioner, water dispenser, freezer, refrigerator |
| Port | Shanghai Ningbo Tianjin Qingdao |
CM8600 Dual System Refrigerant Charging Machine for Refrigerator Assembly Line
The CM86 refrigerant charging machine is specially designed for fast speed refrigerant charging at production lines. It features high speed charging, high accuracy, and multiple functions. The machines are compatible with refrigerants of CFC, HFC, HC, etc. The machine can also be customized according to your special requirements.
Key Features
- Adopt CNC technology allowing data processing capability with accurate and easy operation
- Charging/filling liquid gas R134a, R22, R407C, R410A etc. (for R600a, R290, R32 can be customized)
- Siemens PLC and colorful touch screen control system
- High accuracy flow sensors provide precise data with resolution reaching 1~0.1g
- Wonfulay (our own brand) pneumatic booster ensures stable pressure and large charging quantity supply
- Continuous charging/filling quantity up to 99999g with charging rate of 60g~260g
- Automatic prompt function when refrigerant in the cylinder is low
- Adjustable vacuum time and inspection leak time according to requirements
- Wonfulay (our own brand) filling gun improves charging/filling speed
- Wonfulay (our own brand) high vacuum pump provides quick vacuum reaching 5~10Pa
- Includes vacuum, inspection leak, charging/filling, and refrigerant recovery functions
- Repeat filling accuracy ≤ ± 0.5%
- Easy to move
Product Images
